45
4 Visualization
4.11 Comment Entry
This function can be used to enter a text (max. length 31 characters) that is
entered in the event list when the input is completed.
In curve presentation (in the displayed group), the text entry is marked by a
pencil symbol.
v Chapter 6 "Alarm and Event Lists"
v Chapter 4.3 "Curve Presentation"
v Chapter 4.11 "Comment Entry"
The text can now be found in the event list, under the heading “All events”, but
also under the corresponding batch.
If batches are used (parameter: Device manager
Î
Configuration
Î
Batches/plants
Î
Gen. plant parameters
Î
Number of plants is larger than 0), then the groups have a fixed
assignment to the batches.
Plant number Group Plant (batch)
01…9None
11…91
21…3
4…6
7…9
1
2
Not assigned
31…3
4…6
7…9
1
2
3
