4 Visualization
40
4.9.2 Completed Batches
Batch
evaluation
Completed batches can be evaluated in three different ways:
-Curves (graphical presentation)
-Report (numerical presentation)
-Attachments (e.g. recipes)
h Rotate the control knob to select a type of presentation, then press the
knob to activate this type.
Activating the door symbol in the header closes the selected presentation, and
the batch data will be displayed again.
Change
batch/
plant
The corresponding batch data will be shown in its own batch visualization,
depending on how many plants have been configured.
Batch evaluation
Change batch/plant
