5 Memory Presentation (History)
50
Numerical
measurement
display
This function decides whether the MAX or MIN values are shown in the
“Numerical measurement display”. Min or Max values arise when more
measurements are recorded than are displayed. This will be the case if “Min/
Max recording” is activated in a group operating mode.
Channel step-
on
This function activates the scaling display. Repeatedly activating the function
steps through the scaling for the channels within the group, and then blanks it
out again.
Close memory
presentation
This function starts the presentation of the data that are available in the
internal main memory of the instrument.
5.2 Horizontal presentation
In the display the individual signals run across the screen from right to left
(horizontal presentation).
The same functions as for the vertical presentation apply.
