10 Web server
92
10.9 QuadView
Up to four devices can be visualized with the 4-fold view (QuadView). This ap-
plies to the same device or to two to four different devices. For each display,
different visualizations can be activated (e.g. the curve presentation and the
bar graph display of a device in two views).
Before the 4-fold view can be used the function must first be configured.
Configuration h Left-click "[+]"
h Enter the IP address or the DNS name in the corresponding field and finish
the input by clicking the "Ok" button.
Result: the entered IP addresses (or DNS names) are saved on the PC as
cookies and therefore remain until the cookies are deleted (e.g. with the PC
browser). Visualization starts automatically.
