JUMO LOGOSCREEN - 2 Instrument description; 2.1 Displays and controls

13
2 Device description
A
The CompactFlash memory card must not be removed while it is
being accessed (signal LED is on).
H
The life of the background illumination can be prolonged by
using the parameter “Screen off”.
CompactFlash slot
for data exchange
(measurement data, configuration
data, user lists) between the
recorder and the PC
Setup plug connection
for communication with the
setup program
Header
Status line &
title line
Signal LED
Lights up during
access to the
CompactFlash
memory card.
Ejector for the
CompactFlash
memory card
Numerical
Measurement
Visualization window (diagram)
