3 Operator level (visualization)
30
3.9 Batches/plants
When recording batch processes, a distinction is made between the plant and
the batch.
The instrument can combine and record the data from up to 3 plants as a
batch (batch protocol). The number of batches for a plant is not limited. The
instrument distinguishes between “current batch” and the most recently
“completed batch” for a plant. The number of plants that are used and the
texts in the batch template can be configured on the instrument or in the setup
program.
3.9.1 Current batches
v This display shows the current data for the batch(es). Further information
about entering the texts in the left and right columns can be found in the
Operating Manual B 70.6580.0.
The batch texts on the right-hand side can be entered by using one of the
following options:
Edit batch
Change batch/plant
Start/stop the batch
(only if configured)
Close editing
Batch
status
