Jungheinrich ECR 336 User Manual

G 15
0307.USA
6.5 Checking the electrical fuses
– Prepare the vehicle for maintenance and servicing
(see Section 6.1)
– Open the front cover (see Section 6.2).
– Check all fuses for the correct value as shown in the table and replace if necessary.
Item Designation Fuse protection for: Value
11 2F1 Hydraulic functions 150 A
12 1F1 Travel functions 355 A
13 6F1 Battery capacity measuring circuit 2 A
14 4F1 Horn 3 A
15 F1 Control current circuit 10 A
11 12 13 14 15
