F 5
0705.USA
5 Removing and installing the battery
QwW The vehicle must be in a horizontal position (secured to prevent it rolling
away). To prevent short-circuits, cover batteries with exposed poles or
connectors with a rubber mat. Position the battery connector or battery cable
in such a way that it cannot catch on the vehicle when pulled out from the
battery.
QwW If transporting the battery with a crane harness, check that it has an adequate
load capacity (see battery weight on the battery nameplate on the battery
tray). The crane harness must exert a vertical pull to avoid crushing the
battery tray. Attach the hooks to the sling eyes (7) on the battery in such a
way that when the tension on the crane harness is released, they cannot fall
onto the battery cells.
5.1 Removal, standard design
– Uncover the battery (see Section 3).
– Pull out the battery connector and place it on the battery.
– Close the battery cover.
– Attach the crane harness to the sling eyes (7) and lift out the battery.
7
