Jungheinrich ECR 336 User Manual

H 3
0705.USA
750 Ah battery
Spring B
Remove
lock nut
X X
Spring A
Remove
lock nut
X X X X X X
510 Ah and 600 Ah battery
Spring B
Remove
lock nut
Spring A
Remove
lock nut
X X X X
Fork
overhang
in (mm)
7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185)
23.3 (592) 32.3 (821) 35.3 (897)
42.3 (1075)
Fork
length
in (mm)
35.7 (908)
41.7 (1060) 47.8 (1213) 53.7 (1365) 59.7 (1517) 95.7 (2432)
102.8 (2610)
83.7 (2127) 92.8 (2356) 95.7 (2432)
102.8 (2610)
