Jungheinrich ECR 336 User Manual

0705.USA
D 8
Vehicle with 3600 kg load and 150 mm load carriage travel,
including 510 Ah battery
Drive wheel load
while moving in
fork direction
(level ground)
in lb (kg)
2615 (1186)
2048 (929)
2795 (1268) 2736 (1241) 2965 (1345) 3851 (1747) 3968 (1800) 2701 (1225) 2229 (1011)
2138 (970) 2103 (954)
Drive wheel load
while moving in
drive direction
(level ground)
in lb (kg)
2835 (1286) 2269 (1029) 3016 (1386) 2978 (1351) 3208 (1455) 4094 (1857) 4211 (1910) 2921 (1325) 2449 (1111) 2359 (1070) 2324 (1054)
Load axle
in lb (kg)
7099 (3220) 7705 (3495) 7000 (3175) 6803 (3086) 6612 (2999) 5968 (2707) 5899 (2676) 7297 (3310) 7800 (3538) 7901 (3584)
7961 (3611)
Drive axle
in lb (kg)
3331 (1511)
2765 (1254) 3512 (1593) 3750 (1701) 3979 (1805) 4866 (2207) 4982 (2260) 3417 (1550) 2945 (1336) 2855 (1295) 2820 (1279)
Vehicle weight
in lb (kg)
10430 (4731) 10470 (4749)
10511 (4768)
10551 (4786) 10591 (4804) 10833 (4914) 10882 (4936) 10714 (4860) 10745 (4874) 10756 (4879) 10780 (4890)
Load center
(LC)
in inches (mm)
19.7 (500) 23.6 (600) 23.6 (600) 26.9 (683) 29.9 (759)
47.9 (1216) 51.4 (1305) 41.9 (1064)
46.4 (1178)
47.2 (1200) 47.2 (1200)
Forkover-
hang
in inches
(mm)
7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185) 7.3 (185)
23.3 (592) 32.3 (821) 35.3 (897)
42.3 (1075)
Fork length
in inches
(mm)
35.7 (908)
41.7 (1060) 47.8 (1213) 53.7 (1365) 59.7 (1517) 95.7 (2432)
102.8 (2610)
83.7 (2127) 92.8 (2356) 95.7 (2432)
102.8 (2610)
