Item Control or indicator
Function
17 Coast LED o Flashes:
– when a jog button is pressed and the vehicle is
coasting.
Lights up:
– when the battery capacity is down between 30%
and 0% with a standard battery.
– when the battery capacity is down between 40%
and 0% with a maintenance-free battery.
18 Jog button o Travel switch for travel in tiller direction. Coasting
at 5.6 km/h (3.5 mph).
19 Battery connector
(EMERGENCY STOP)
t The electric circuit is broken, all electrical functions
switch off and the vehicle brakes are automatically
applied.
t = Fitted as standard o = Optional extra
