0705.USA
E 10
Vehicle tiller with locking lever (13, o)
NOTICE In ride-on mode or order picking mode the tiller can be locked in the travel
position with the locking lever (13).
– Pull the tiller locking lever (13) up.
– Move the tiller down until it locks.
– When the tiller is locked, the vehicle is in coasting mode.
– Press the jog button (7, o / 14, o).
The vehicle starts moving in the direction of travel V at 5.6 km/h (3.5 mph), max.
– Release the jog button (7, o / 14, o).
The vehicle coasts for a predefined distance and is then braked automatically.
To brake the vehicle during coasting:
– Move the tiller to the lower or upper braking range B (the lock is released if the tiller
is moved toward the upper braking range B)
or
– Press the brake button (15, o)
NOTICE The LED (17) flashes when the vehicle is in coasting mode.
V
7
13
14
15
15
14
F
B
B
