Jungheinrich EJC 214 - EJC 212 Z; 214 Z; 216 Z; 220 Z

7.2 EJC 212z / 214z / 216z / 220z
Load handler emergency lowering
Requirements
– Load handler is not in the rack.
Tools and Material Required
– Key (SW8)
– Torque wrench setting range 1-4 Nm
Procedure
• Park the truck securely, see page 84.
• Open the front panel, see page 185.
• Loosen the lock nut (75) on the valve block.
• Remove the valve screw (76) in stages (anti-clockwise).
The load handler is lowered.
Z
After the emergency lowering insert the valve screw (76) as far as the stop (1.5 Nm
+0.5 Nm) and secure with the lock nut (75).
75
76
116
04.19 en-GB
