4.5 Checking the hydraulic oil level
Check oil level
Requirements
– Lower the load handler.
– Prepare the truck for maintenance and repairs, see page 184.
Procedure
• Lift off the front panel, see page 185
• Check the oil level in the hydraulic reservoir.
Z
There are markings on the hydraulic reservoir. The oil level must be checked
when the load handler and support-arm lift are lowered.
• If necessary, add transmission oil of the correct grade, see page 183(refer to
table).
Z
For the first filling approximately 0,6 l more hydraulic oil should be added.
The oil level has now been checked.
Z
If a leak is discovered in the hydraulics (cylinder; unions, lines), the truck must be
decommissioned and repaired by specialist personnel.
Marking Litres Lift heights (h
3
)
ZT ZZ DZ
3 approx. 8.3 - - -
2 approx. 7.5 EJC 214-220
1 approx. 6.5 EJC 214-220 EJC 214-220
Marking Litres Lift heights (h
3
)
ZT ZZ DZ
3 approx. 8.3 - - -
2 approx. 7.5 - - EJC 214z-220z
1 approx. 6.5 EJC 212z-220z EJC 212z-220z EJC 212z
190
04.19 en-GB
