Jungheinrich EJC 214 - Truck Capacity Plate

5.3 Truck capacity plate
Previous capacity plate
25
Current capacity plate
25
The capacity plate (25) indicates the maximum capacity Q (in kg) for a given load
centre distance D (in mm) and corresponding lift height H (in mm) for the truck when
raising a load.
Example of how to calculate the maximum capacity:
The maximum capacity is Q1 at a load centre G within the load centre distance D1
and a lift height up to HH1.
37
04.19 en-GB
