Jungheinrich HC 10 User Manual

0502.GB
B 4
3 Technical data - standard version
A
Technical data specified according to VDI 2198.
Technical data are subject to alteration and additions.
3.1 Performance data for standard trucks
3.2 Dimensions
* Ast includes a safety distance of 200 mm
3.3 Batteries and motor output
f
It is essential that the battery type for the double hoist frame model is observed, as
the weight of the batteries acts as a counterweight and must be present in the vehicle.
Designation HC
Q Rated load capacity 1000 kg
C Load centre 600 mm
Lifting speed with / without load 8 / 10 cm/s
Lowering speed with / without load 27 / 15 cm/s
Designation HC single hoist
frame
HC double hoist
frame
h
1
Height 1295/1975/2175 1775/1975 mm
h
2
Free-lift - 175 mm
h
3
Lifting height 814/1514/1714 2414/2814 mm
h
4
Height, mast extended 1295/1995/2195 2910/3310 mm
h
13
Height, fork lowered 86 86 mm
s Thickness of fork 62 62 mm
y Wheel base, load part lowered 1055 1055 mm
l Fork length 1150 1150 mm
l
1
Truck length 1651 1651 mm
l
2
Front section length 501 501 mm
e Fork width 160 160 mm
b
1
Truck width 850 850 mm
b
5
Distance between the forks,
outside
520/560 520/560
mm
b
11
Track width of load section 400 400 mm
m
2
Ground clearance 24 24 mm
Wa Turning radius 1650 1650 mm
Ast* Aisle width
800x1200 in longitudinal dir.
3170 3170 mm
HC single hoist frame HC double hoist frame
Battery 2 x 12 V / 55 Ah in series 2 x 12 V / 110 Ah in series
Battery weight Approx. 2 x 17 kg Approx. 2 x 28 kg
Motor output,
S3 12%
1,8 kW 1,8 kW
0502.GB
B 4
3 Technical data - standard version
A
Technical data specified according to VDI 2198.
Technical data are subject to alteration and additions.
3.1 Performance data for standard trucks
3.2 Dimensions
* Ast includes a safety distance of 200 mm
3.3 Batteries and motor output
f
It is essential that the battery type for the double hoist frame model is observed, as
the weight of the batteries acts as a counterweight and must be present in the vehicle.
Designation HC
Q Rated load capacity 1000 kg
C Load centre 600 mm
Lifting speed with / without load 8 / 10 cm/s
Lowering speed with / without load 27 / 15 cm/s
Designation HC single hoist
frame
HC double hoist
frame
h
1
Height 1295/1975/2175 1775/1975 mm
h
2
Free-lift - 175 mm
h
3
Lifting height 814/1514/1714 2414/2814 mm
h
4
Height, mast extended 1295/1995/2195 2910/3310 mm
h
13
Height, fork lowered 86 86 mm
s Thickness of fork 62 62 mm
y Wheel base, load part lowered 1055 1055 mm
l Fork length 1150 1150 mm
l
1
Truck length 1651 1651 mm
l
2
Front section length 501 501 mm
e Fork width 160 160 mm
b
1
Truck width 850 850 mm
b
5
Distance between the forks,
outside
520/560 520/560
mm
b
11
Track width of load section 400 400 mm
m
2
Ground clearance 24 24 mm
Wa Turning radius 1650 1650 mm
Ast* Aisle width
800x1200 in longitudinal dir.
3170 3170 mm
HC single hoist frame HC double hoist frame
Battery 2 x 12 V / 55 Ah in series 2 x 12 V / 110 Ah in series
Battery weight Approx. 2 x 17 kg Approx. 2 x 28 kg
Motor output,
S3 12%
1,8 kW 1,8 kW
