0708.GB

F 6

5.1 Fuels, coolants and lubricants

Handling consumption-type material: Consumption-type material must always be

handled properly. Manufacturer’s instructions are to be observed.

Improper handling is injurious to health, life and environment. Consumption-type ma-

terials must be stored in adequate containers. They might be inflammable and, the-

refore, must not come into contact with hot components or open fire.

When filling in consumption-type materials, use clean containers only. Mixing con-

sumption-type materials of different grades or qualities is prohibited, except if mixing

is expressly prescribed in these operating instructions.

Avoid spilling. Spilt liquid must be removed immediately using a suitable binding

agent and the mixture of consumption-type material and binding agent is to be dispo-

sed of according to the regulations.

Grease nipple

6 Notes regarding maintenance

6.1 Preparing the truck for maintenance work

All required safety measures must be taken to prevent any accidents in the course of

the servicing and maintenance operations. The following preparatory operations

must be performed:

– Park the truck and render it safe (see chapter E).

When work has to be performed under the raised fork or under the jacked up truck,

suitable measures must be taken to prevent any dropping, tilting or slipping of the fork

or truck. When lifting the truck, the instructions contained in chapter “Transportation

and commissioning” have to be observed.

When performing work on the parking brake, the truck must be secured against mo-

ving.

Code Order No Quantity Designation Used for

A 29 200 670 5,0 l ISO VG-32 Hydraulic system

E 29 201 430 1,0 kg Grease, DIN 51825 Lubrcation

G 29 201 280 0,51 kg Chain spray Chains

Code Saponification

type

Dropping

point °C

Working penetrati-

on at 25 °C

NLGI

class

Operating

temperature °C

E Lithium 185 265 - 295 2 -35/+120
