■ Installing an Intraconnect Module in an EX4500 Switch on page 79
■ Removing an Intraconnect Module from an EX4500 Switch on page 123
■ Installing a Transceiver in an EX Series Switch on page 81
■ Removing a Transceiver from an EX Series Switch on page 126
Related Topics ■ Cooling System and Airflow in an EX4500 Switch on page 20
■ AC Power Supply in EX4500 Switches on page 18
■ Uplink Modules in EX4500 Switches on page 23
■ Intraconnect Module in EX4500 Switches on page 25
■ Optical Interface Support in EX4500 Switches on page 31
Removing a Power Supply from an EX4500 Switch
The power supply in EX4500 switches is a hot-removable and hot-insertable
field-replaceable unit (FRU): You can remove and replace it without powering off the
switch or disrupting switch functions.
Before you begin removing a power supply from the switch:
■ Ensure you understand how to prevent ESD damage. See “Prevention of
Electrostatic Discharge Damage on EX Series Switches” on page 174.
Ensure that you have the following parts and tools available to remove the power
supply from the switch chassis:
■ An antistatic bag or an antistatic mat
■ Replacement power supply or a cover panel for the power supply slot
CAUTION: Do not leave the power supply slot empty for a long time while the switch
is operational. Either replace the power supply promptly or install a cover panel over
the empty slot.
To remove a power supply from the switch (see Figure 46 on page 119):
1. Place the antistatic bag or the antistatic mat on a flat, stable surface.
2. Attach the electrostatic discharge (ESD) grounding strap to your bare wrist, and
connect the strap to the ESD point on the chassis.
3. Disconnect power from the switch by performing one of the following tasks:
■ If the AC power source outlet has a power switch, set it to the OFF (0)
position.
■ If the AC power source outlet does not have a power switch, gently pull out
the male end of the power cord connected to the power source outlet.
118 ■ Removing a Power Supply from an EX4500 Switch
Complete Hardware Guide for EX4500 Ethernet Switches
