Chapter 9
Installing Switch Components
■ Installing and Removing EX4500 Switch Hardware Components on page 73
■ Installing a Power Supply in an EX4500 Switch on page 74
■ Installing a Fan Tray in an EX4500 Switch on page 75
■ Installing an Uplink Module in an EX4500 Switch on page 77
■ Installing an Intraconnect Module in an EX4500 Switch on page 79
■ Installing a Transceiver in an EX Series Switch on page 81
Installing and Removing EX4500 Switch Hardware Components
The EX4500 switch chassis is a rigid sheet-metal structure that houses the hardware
components. The field-replaceable units (FRUs) in EX4500 switches are:
■ Power supply
■ Fan tray
■ Uplink module
■ Intraconnect module
■ SFP transceiver
■ SFP+ transceiver
The power supply, fan tray, uplink module, and transceivers are hot-removable and
hot-insertable: You can remove and replace them without powering off the switch
or disrupting switch functions.
See these topics for instructions for installing and removing components:
■ Installing a Power Supply in an EX4500 Switch on page 74
■ Removing a Power Supply from an EX4500 Switch on page 118
■ Installing a Fan Tray in an EX4500 Switch on page 75
■ Removing a Fan Tray from an EX4500 Switch on page 119
■ “Installing an Uplink Module in an EX4500 Switch” on page 77.
■ Removing an Uplink Module from an EX4500 Switch on page 121
■ Installing an Intraconnect Module in an EX4500 Switch on page 79
Installing and Removing EX4500 Switch Hardware Components ■ 73
