Chapter 7
Planning Power Requirements
■ AC Power Specifications for EX4500 Switches on page 57
■ AC Power Cord Specifications for an EX4500 Switch on page 57
AC Power Specifications for EX4500 Switches
Table 23 on page 57 lists the AC power specifications for a 1000 W power supply
used in EX4500 switches.
Table 23: Power Specifications for an AC Power Supply Used in EX4500 Switches
SpecificationsItem
Operating range—100–240 VACAC input voltage
50–60 HzAC input line frequency
12 AAC input current rating
1000 WAC output power
Related Topics AC Power Supply in EX4500 Switches on page 18■
■ AC Power Supply LEDs in EX4500 Switches on page 19
■ AC Power Cord Specifications for an EX4500 Switch on page 57
AC Power Cord Specifications for an EX4500 Switch
Each AC power supply for the EX4500 switch has a single AC appliance inlet located
on the power supply that requires a dedicated AC power feed. Most sites distribute
power through a main conduit that leads to frame-mounted power distribution panels,
one of which can be located at the top of the rack that houses the switch. An AC
power cord connects each power supply to the power distribution panel.
Each detachable AC power cord is 2.5 meters (approximately 8 feet) long. The
appliance coupler at the female end of the cord inserts into the AC appliance inlet
on the faceplate of the AC power supply. The coupler type is C19 as described by
the International Electrotechnical Commission (IEC) standard 60320. The plug at the
AC Power Specifications for EX4500 Switches ■ 57
