Figure
6:
Front-to-Back
Airflow
Through
the
SSR120
Chassis
LTE
Support
on
SSR120
Appliances
IN
THIS
SECTION
Overview
|
15
Antennas
|
16
Firmware
Upgrade
Support
|
17
Overview
The
SSR120
portfolio
consists
of
models
with
or
without
LTE
support.
The
LTE
support
is
provided
through
the
in-built
LTE
module
that
operates
on
both
3G
and
4G
networks.
The
SSR120
supports
only
a
single
SIM
card.
Table
5
on
page
16
provides
a
summary
of
the
models
that
support
LTE.
15
14
16
