Console Port Connector Pinouts for SSR120
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect to a console
management device. The default baud rate for the console port is 115200 baud. Table 12 on page 26
provides the pinout information for the RJ-45 console connector. An RJ-45 cable and RJ-45 to DB-9
adapter are supplied with the appliance.
Table 12: Console Port Connector Pinouts
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
GroundGround4
GroundGround5
Receive dataRxD Input6
Data set readyDSR Input7
Clear to sendCTS Input8
Pluggable Transceivers Supported on SSR120
The 1 GbE RJ-45/SFP combo port on the SSR120 supports the following transceivers:
•
EX-SFP-1GE-SX
•
EX-SFP-1GE-LX
26
