8 TECHNICAL INFORMATION
8.1 LOW VOLTAGE CONNECTIONS
Label Type
IN1 2 Way Energizer control input 1 (dry contact momentary)
internally wired in parallel with the key switch. Can
be used for a remote switch or a radio receiver. The
receiver may be powered from the keypad +12V termi-
nal.
GATE 2 Way Energizer control input 2 (dry contact). Default func-
armed and the gate is opened, it will trigger the gate
make the energizer alternate between Low Power and
High Power mode.
KEYPAD 3 Way Supplies power and data line for an external keypad.
The +12 source on these terminals is protected with
SIREN 2 Way Switched 12V output. 30W max, shared between
switched
STROBE 2 Way Switched 12V output. 30W max, shared between
switched
