OTHERS – Specifications –
 General
Recording system :DV system (SP mode only)
Signal system : NTSC/PAL (PAL for playback and
DV input only)
Cassette tape : Standard/ mini DV cassette tape
Tape width : 6.35mm
Tape speed : 18.812mm/s (NTSC)
18.831mm/s (PAL)
Recording/ playback time
: 276 minutes (LA-DV276)
60 minutes (M-DV60)
Fast forward/ rewind time
: About 3 minutes (LA-DV276)
About 1 minute (M-DV60)
Power : DC12 V } (By the supplied AC
adapter)
Power consumption :24W
External dimension : 212 mm (W)  88mm (H) 
327mm (D) (Excluding protruding
parts)
Weight : About 4.5 k˝
Allowable operating temperature
: 5˚C to 40˚C
Allowable storage temperature
: –20˚C to 60˚C
Allowable operating RH
: 30%RH to 80%RH
 Video
Recording format :8 bit, 13.5 MHz,
4:1:1 (NTSC)
4:2:0 (PAL)
Video input
Line (composite) : 1.0 V (p-p), 75 Ø unbalanced
Y/C Y : 1.0 V (p-p), 75 Ø unbalanced
C : 0.286 V (p-p), 75 Ø unbalanced
Component Y : 1.0 V (p-p), 75 Ø unbalanced
(100%, Color Bar)
R-Y : 0.7 V (p-p), 75 Ø unbalanced
(75%, Color Bar, Setup 7.5%)
B-Y : 0.7 V (p-p), 75 Ø unbalanced
(75%, Color Bar, Setup 7.5%)
Video output
Line (composite) : 1.0 V (p-p), 75 Ø unbalanced
Y/C Y : 1.0 V (p-p), 75 Ø unbalanced
C : 0.286 V (p-p) (NTSC) /
0.3 V (p-p) (PAL)
75 Ø unbalance
Component Y : 1.0 V (p-p), 75 Ø unbalanced
(100%, Color Bar)
R-Y : 0.7 V (p-p), 75 Ø unbalanced
(75%, Color Bar, Setup 7.5%)
B-Y : 0.7 V (p-p), 75 Ø unbalanced
(75%, Color Bar, Setup 7.5%)
Monitor (composite) : 1.0 V (p-p), 75 Ø unbalanced
(On-screen display)
Horizontal resolution : At least 500 lines
S/N : At least 50 dB
 Audio
Recording format : 16 bit, 48kHz, 2-channels
PCM audio/12 bit, 32kHz,
4-channel PCM audio
Number of track :2 (16 bit,48kHz) /
4 (12 bit, 32kHz)
Audio input :–8dBs, 10 kØ unbalanced
Mike input : –60 dBs, 3 kØ unbalanced
Audio output :–8dBs, 1 kØ unbalanced
Headphone :–∞ to – 20 dBs,
33 kØ unbalanced (stereo)
Monitor :–8dBs, 1 kØ unbalanced
(monaural)
Frequency characteristics
: 20 Hz to 20 kHz (48kHz)
20 Hz to 16 kHz (32kHz)
XLR terminal (Option)
Input : + 4 dBs,high impedance,balanced
Output : + 4 dBs,low impedance,balanced
 DV interface
Input/output : IEEE1394
 Time code
LTC input :0±6 dBs, high impedance
LTC output :0±6 dBs, low impedance
 AC adapter
Input :AC 100 V to 120 V`,
50 Hz/60 Hz x 1.5 A
Output : DC 12 V } 5 A
 Accessories
AC adapter ................................................................... 1
Power cord ................................................................... 1
