19
¤ [SERIAL REMOTE OUT] terminal
(mini jack)
• This terminal is for direct through-output of
serial commands of the serial remote input
terminal. (Only with OPERATE ON)
• If REPLICATION of the SYSTEM (2/2) Menu
screen is set to SERIAL, this terminal out-
puts REC commands when BR-DV6000 be-
gins playback. (REPLICATION mode)Use this
function to connect BR-DV6000 to a dubbing
device for dubbing its playback video or play-
back sound.
‹
[REMOTE 1] RS-422A terminal
(D-SUB 9-PIN)
This terminal is for connecting to an RS-422A
serial interface-compatible editing remote con-
troller (e.g. RM-G820).
With this terminal, BR-DV6000 can be used as
a player or recorder of an editing system.
To operate BR-DV6000 with RS-422A, perform
the following settings.
• Set REMOTE SEL 9-PIN in the REMOTE (1/
2) Menu screen to “ON”.
• Set the 4 REMOTE / LOCAL switch on the
front panel to “REMOTE”.
Memo
● Use screws, of the inch, not metric, system,
for fastening the connectors.
● This part can be replaced by the RS-232C
serial interface board SA-K46U (sold sepa-
rately).
Consult your JVC authorized service agent
for such replacements.
› [REMOTE 2] JVC Bus terminal
(12-PIN)
This terminal is for connecting to the JVC bus
interface-compatible editing remote controller
(RM-G800, RM-G805).
With this terminal, BR-DV6000 can be used as
a player or recorder of an editing system.
To operate BR-DV6000 with this terminal, per-
form the following settings.
• Set REMOTE SEL JVC in the REMOTE
(1/2) Menu screen to “ON”.
• Set the 4 REMOTE / LOCAL switch on the
front panel to “REMOTE”.
fi Slot cover for an optional board
This cover can be removed to install any of the
following optional boards.
• SA-DV6000 network board
• SA-X61U AUDIO XLR IN board (2ch)
• SA-X62U AUDIO XLR OUT board (2ch)
Memo
● With the SA-X61U AUDIO XLR IN board in-
stalled, whether sound signals are input to
the XLR IN terminal or the AUDIO IN termi-
nal can be selected with AUDIO INPUT SEL
in the AUDIO MENU. If the MIC terminal is in
use, the MIC terminal precedes.
● With the SA-X62U AUDIO XLR OUT board
installed, the audio channel to which signals
are output can be selected with the AUDIO
OUTPUT switch.
