Adjusting the Digital Video Cassette Camera with JVC Service Support System Software
95
Page 1
Byte Definition Other
1 Year
2 Month
3 Day
4 Hour
5 Minute
6 Second
7 CPU Initialization See Table 20
8 Focus Error Data - Low Control Data See Table 21
9 Special Effect Setting Low - Order Data See Table 22
10 Special Effect Setting High-Order Data See Table 23
11 Y Data Addend Low-Order Byte
12 Y Data Addend High-Order Byte
13 White Balance Preset Number
14 White Balance Color Temperature Evaluation Value (Red)
15 White Balance Color Temperature Evaluation Value (Blue)
16 White Balance Mode
Table 19 Data Dump - Standard Mode, Page 1
CPU Initialization
Bit No Control In Detail High Low
3 Iris Initialization End Flag Initialization Complete Initializing
2 EIS Initialization End Flag Initialization Complete Initializing
1 WB Initialization End Flag Initialization Complete Initializing
0 AF Initialization End Flag Initialization Complete Initializing
Table 20 Data Dump - CPU Initialization
Focus Error Data
Bit Description High Low
7 Lens Initialization Error Data Initialization Failure Normal
6 Lens Pulse Error Data Pulse Error Detected Not Detected
2 Lens Control Mode Under Software Control Under Control of Zoom
Switch
1 Low Control Data Low Control Status Normal operation
0 Auto Macro Operation Data Auto Macro Mode Normal operation
Table 21 Data Dump - Focus Error Data
