Adjusting the Digital Video Cassette Camera with JVC Service Support System Software

Sensor (1)

Bit Description High Low

7 End Sensor End Normal

6 Start Sensor Start Normal

5 REC Safety Record Disabled Record Enabled

4 Dew Sensor Dew Normal

3 Tape Existence Loaded Not Loaded

2 Dust Sensor Dusty Normal

1 Tape Type MP ME

0 PB Tape Speed LP SP

Table 27 Data Dump - Sensor (1)

Sensor (2)

Bit Description High Low

7 ITT Detected Not Detected

6 Mode Shift Shifting Shift Ends

5 Cleaning Tape Cleaning Tape Cleaning Tape

4 In Recording Recording from next Frame Recording to the 2nd Frame

3 0 Point In Detection Normal

2 1394 Cable Detected Not Detected

1 Tape Detected Not Detected

0 1394 Signal Detected Not Detected

Table 28 Data Dump - Sensor (2)

Sensor (3)

Bit Description High Low

7 AGCMS Copy Inhibit Not Detected

2 Emergency Mode Off On

1 PB Encoding Mode 11: 32 kHz 12 Bit 00: 48 kHz

0 PB Encoding Mode 10: 32 kHz 16 Bit 01: 44.1 kHz

Table 29 Data Dump - Sensor (3)

Sensor (4)

Bit Description High Low

7 VCGMS Copy Inhibit Not Detected

1 PB Squeeze Squeeze Record Detected Not Detected

0 PB Cinema Cinema Record Detected Not Detected

Table 30 Data Dump - Sensor (4)
