Remove the screw A on the right side of the R/P
head.
Remove the screw B on the left side of the R/P
head.
Prior to performing the following procedure, remove
the
cassette mechanism assembly.
1.
2.
1.
2.
Removing the R/P head.
(See Fig.1 and 2)
Remove the screw C fixing the erase head.
1.
Remove the erase head. (See Fig.1)
Pull out the pinch roller stopper.
Pull out the pinch roller.
Remove the pinch roller. (See Fig.3)
<Cassette mechanism section>
Fig.1
Fig.2
Fig.3
R/P Head
R/P Head
E. Head
Spring
Pinch roller
A
A
B
B
C
Pinch roller
Pinch roller
stopper
