MX-GA77
3-15
Item
Parts number Parts name Ar
ea
Electrical parts list (Front board)
Remarks
Block No. 02
A
FR266 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR267 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR268 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR269 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR270 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR271 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR272 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR273 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR274 2001-000613 CARBON RESISTOR 3.9K 5% 1/8W
FR275 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR276 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR277 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR278 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR279 2001-000008 CARBON RESISTOR 15K 5% 1/8W
FR280 2001-000660 CARBON RESISTOR 33K 5% 1/8W
FR281 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR282 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR283 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR284 2001-001178 CARBON RESISTOR 680 5% 1/2W
FR285 2001-001178 CARBON RESISTOR 680 5% 1/2W
FR286 2001-001178 CARBON RESISTOR 680 5% 1/2W
FR287 2802-001174 RESONATOR 10MHZ 0.5%
FR288 2003-000500 OMF RESISTOR 150 5% 1W
FR289 3406-001085 SWITCH-ROTARY DC5V NO CLICK
FR290 3406-001084 SWITCH-ROTARY DC5V 0.5MA CLICK
FR291 3406-001084 SWITCH-ROTARY DC5V 0.5MA CLICK
FR292 3404-001048 SWITCH-TACT DC12V 50MA
FR293 3404-001048 SWITCH-TACT DC12V 50MA
FR294 3404-001048 SWITCH-TACT DC12V 50MA
FR295 3404-001048 SWITCH-TACT DC12V 50MA
FR296 3404-001048 SWITCH-TACT DC12V 50MA
FR297 3404-001048 SWITCH-TACT DC12V 50MA
FR298 3404-001048 SWITCH-TACT DC12V 50MA
FR299 3404-001048 SWITCH-TACT DC12V 50MA
FR300 3404-001048 SWITCH-TACT DC12V 50MA
FR301 3404-001048 SWITCH-TACT DC12V 50MA
FR302 3404-001048 SWITCH-TACT DC12V 50MA
FR303 3404-001048 SWITCH-TACT DC12V 50MA
FR304 3404-001048 SWITCH-TACT DC12V 50MA
FR305 3404-001048 SWITCH-TACT DC12V 50MA
FR306 3404-001048 SWITCH-TACT DC12V 50MA
FR307 3404-001048 SWITCH-TACT DC12V 50MA
FR308 3404-001048 SWITCH-TACT DC12V 50MA
FR309 3404-001048 SWITCH-TACT DC12V 50MA
FR310 3404-001048 SWITCH-TACT DC12V 50MA
FR311 3404-001048 SWITCH-TACT DC12V 50MA
FR312 3404-001048 SWITCH-TACT DC12V 50MA
FR313 3404-001048 SWITCH-TACT DC12V 50MA
FR314 3404-001048 SWITCH-TACT DC12V 50MA
FR315 3404-001048 SWITCH-TACT DC12V 50MA
FR316 3404-001048 SWITCH-TACT DC12V 50MA
FR317 3404-001048 SWITCH-TACT DC12V 50MA
FR318 3404-001048 SWITCH-TACT DC12V 50MA
FR319 3404-001048 SWITCH-TACT DC12V 50MA
FR320 3404-001048 SWITCH-TACT DC12V 50MA
FR321 3404-001048 SWITCH-TACT DC12V 50MA
FR322 3404-001048 SWITCH-TACT DC12V 50MA
FR323 0504-001123 DIGI TRANSISTOR KRC103M 400MW
FR324 0504-001123 DIGI TRANSISTOR KRC103M 400MW
FR325 0504-001123 DIGI TRANSISTOR KRC103M 400MW
FR326 0502-001063 TRANSISTOR KTD2092 25W
FR327 0501-002409 TRANSISTOR KTC945B 625MW
FR328 0501-000422 TRANSISTOR KTA1273
FR329 0501-000422 TRANSISTOR KTA1273
FR330 0501-000422 TRANSISTOR KTA1273
FR331 0501-002375 TRANSISTOR KTC8050 625MW
FR332 0501-002375 TRANSISTOR KTC8050 625MW
FR333 0501-002375 TRANSISTOR KTC8050 625MW
FSR01 2103-000341 VR-SEMI 2K 30% 1/10W
HD201 0401-000101 DIODE 1N4148 100V
HJACK 3722-000351 JACK-PHONE 11P 3.5PI AG
LD101 0601-001739 LED ROUND RED
LD102 0601-001739 LED ROUND RED
LD103 0601-001739 LED ROUND RED
LD104 0601-001739 LED ROUND RED
LD105 0601-001739 LED ROUND RED
LD106 0601-001739 LED ROUND RED
LD107 0601-001739 LED ROUND RED
LD108 0601-001739 LED ROUND RED
LD201 0601-001739 LED ROUND RED
LD202 0601-001739 LED ROUND RED
LD203 0601-001739 LED ROUND RED
LD204 0601-001739 LED ROUND RED
PCB AH41-00552A PCB FRONT MX-GA77
UCW01 3708-001577 CONNECTOR 30P 1.25MM
UCW02 3708-000492 CONNECTOR 9P 1.25MM
UCW03 3708-000492 CONNECTOR 9P 1.25MM
UCW04 3708-000454 CONNECTOR 22P 1.25MM ST
UCW05 3708-000178 CONNECTOR 16P 1.25MM AN
UC001 2201-000783 C.CAPACITOR 100NF +80-20% 50V
UC101 2401-002180 E.CAPACITOR 2.2UF 20% 50V
UC102 2401-000759 E.CAPACITOR 220NF 20% 50V
UC103 2401-001355 E.CAPACITOR 470UF 20% 10V
UC104 2401-000240 E.CAPACITOR 100UF 20% 10V
UC105 2201-000389 C.CAPACITOR 0.022NF 5% 50V
UC106 2201-000389 C.CAPACITOR 0.022NF 5% 50V
UC107 2202-000854 C.CAPACITOR 47NF 30% 50V
UC108 2202-000854 C.CAPACITOR 47NF 30% 50V
UC109 2202-000796 C.CAPACITOR 1NF 10% 50V
UC110 2201-000565 C.CAPACITOR 47NF +80-20% 50V
UC111 2401-000475 E.CAPACITOR 10UF 20% 50V
UC112 2202-000854 C.CAPACITOR 47NF 30% 50V
UC113 2401-000475 E.CAPACITOR 10UF 20% 50V
UC114 2201-000783 C.CAPACITOR 100NF +80-20% 50V
UC115 2401-000240 E.CAPACITOR 100UF 20% 10V
UC116 2401-001364 E.CAPACITOR 470UF 20% 16V
UC118 2401-000778 E CAPACITOR 220UF 20% 10V
UC130 2401-000240 E.CAPACITOR 100UF 20% 10V
UC131 2201-000783 C.CAPACITOR 100NF +80-20% 50V
UC132 2202-000797 C.CAPACITOR 10NF 30% 16V
UC133 2202-000780 C.CAPACITOR 100NF +80-20% 50V
UD01 0401-000101 DIODE 1N4148 100V
UD03 0401-000101 DIODE 1N4148 100V
UD09 0401-000101 DIODE 1N4148 100V
UD101 0401-000101 DIODE 1N4148 100V
UD102 0401-000101 DIODE 1N4148 100V
UD103 0402-000127 DIODE 1N4002 100V 1A
UD104 0401-000101 DIODE 1N4148 100V
UD105 0402-000127 DIODE 1N4002 100V 1A
UD106 0402-000127 DIODE 1N4002 100V 1A
UD107 0402-000127 DIODE 1N4002 100V 1A
UD108 0402-000127 DIODE 1N4002 100V 1A
UD109 0402-000127 DIODE 1N4002 100V 1A
UD110 0402-000127 DIODE 1N4002 100V 1A
UD25 0401-000101 DIODE 1N4148 100V
UIC01 AH11-00095A MASK ROM LC876764C-51N5
Item
Parts number Parts name Ar
ea
Remarks
A
