MX-GA77
3-16
Item
Parts number Parts name Ar
Electrical parts list (Front board)
Remarks
Block No. 02
A
UIC02 AC59-60060A MODULE REMOCON GP1U281R SHARP
UIC03 0904-001621 IC PT8300 28P
UIC04 0904-001621 IC PT8300 28P
UX101 2801-001394 CRYSTAL 32.768KHZ 20PPM
VFD AH07-00098A VF DISPLAY BJ904GNK
ZD101 0403-000341 ZENER DIODE UZ3.3B 3.3V
ZD102 0403-000341 ZENER DIODE UZ3.3B 3.3V
ZD103 0403-000341 ZENER DIODE UZ3.3B 3.3V
ZD104 0403-000361 ZENER DIODE UZ6.2BSB 6.2V
To Next Page
