MX-GA77
3-17
Item
Parts number Parts name Ar
ea
Electrical parts list (Amp. board)
Remarks
Block No. 03
A
ACW1 3708-001167 CONNECTOR 14P 1.25MM ST
ACW2 3711-003113 CONNECTOR 9P 1R 2.5MM ST
AC10L 2202-000263 C.CAPACITOR 470PF 10% 50V
AC10R 2202-000263 C.CAPACITOR 470PF 10% 50V
AC11L 2201-000557 C.CAPACITOR 0.47NF 10% 50V
AC11R 2201-000557 C.CAPACITOR 0.47NF 10% 50V
AC12L 2201-000838 C.CAPACITOR 0.003NF 0.25PF
AC12R 2201-000838 C.CAPACITOR 0.003NF 0.25PF
AC13L 2301-000375 M.CAPACITOR 100NF 10% TP50V
AC13R 2301-000375 M.CAPACITOR 100NF 10% TP50V
AC20L 2202-000263 C.CAPACITOR 470PF 10% 50V
AC20R 2202-000263 C.CAPACITOR 470PF 10% 50V
AC21L 2201-000144 C.CAPACITOR 0.1NF 5% 50V
AC21R 2201-000144 C.CAPACITOR 0.1NF 5% 50V
AC22L 2201-000838 C.CAPACITOR 0.003NF 0.25PF
AC22R 2201-000838 C.CAPACITOR 0.003NF 0.25PF
AC25L 2301-000375 M.CAPACITOR 100NF 10% TP50V
AC25R 2301-000375 M.CAPACITOR 100NF 10% TP50V
AC50L 2201-000381 C.CAPACITOR 22NF +80% 50V
AC50R 2201-000381 C.CAPACITOR 22NF +80% 50V
AC51L 2201-000381 C.CAPACITOR 22NF +80% 50V
AC51R 2201-000381 C.CAPACITOR 22NF +80% 50V
AC603 2201-000783 C.CAPACITOR 100NF +80-20% 50V
AC604 2201-000783 C.CAPACITOR 100NF +80-20% 50V
AC607 2201-000547 C.CAPACITOR 4.7NF 20% 500V
AC608 2201-000547 C.CAPACITOR 4.7NF 20% 500V
AD100 0401-000101 DIODE 1N4148 100V
AD303 0402-000127 DIODE 1N4002 100V 1A
AE10L 2401-002180 E.CAPACITOR 2.2UF 20% 50V
AE10R 2401-002180 E.CAPACITOR 2.2UF 20% 50V
AE100 2401-000357 E.CAPACITOR 100UF 0.2 50V
AE101 2401-001164 E.CAPACITOR 33UF 20% 16V
AE102 2401-000357 E.CAPACITOR 100UF 0.2 50V
AE103 2401-000357 E.CAPACITOR 100UF 0.2 50V
AE11L 2401-000438 E.CAPACITOR 10UF 20% 25V
AE11R 2401-000438 E.CAPACITOR 10UF 20% 25V
AE20L 2401-002180 E.CAPACITOR 2.2UF 20% 50V
AE20R 2401-002180 E.CAPACITOR 2.2UF 20% 50V
AE200 2401-000230 E.CAPACITOR 100UF 20% 100V
AE201 2401-000230 E.CAPACITOR 100UF 20% 100V
AE202 2401-000230 E.CAPACITOR 100UF 20% 100V
AE203 2401-000357 E.CAPACITOR 100UF 0.2 50V
AE204 2401-000357 E.CAPACITOR 100UF 0.2 50V
AE205 2401-000230 E.CAPACITOR 100UF 20% 100V
AE21L 2401-000438 E.CAPACITOR 10UF 20% 25V
AE21R 2401-000438 E.CAPACITOR 10UF 20% 25V
AE50L 2401-000459 E.CAPACITOR 10UF 20% 35V
AE50R 2401-000459 E.CAPACITOR 10UF 20% 35V
AE500 2401-001893 E.CAPACITOR 100UF 20% 16V
AE501 2401-001893 E.CAPACITOR 100UF 20% 16V
AJW9 2001-000331 CARBON RESISTOR 12K 5% 1/8W
AL10L AH27-90001A COIL-SPRING 2.2UH SPRING
AL10R AH27-90001A COIL-SPRING 2.2UH SPRING
AL20L AH27-90001A COIL-SPRING 2.2UH SPRING
AL20R AH27-90001A COIL-SPRING 2.2UH SPRING
A
Q
10L 0501-002375 TRANSISTOR KTC8050 625MW
A
Q
10R 0501-002375 TRANSISTOR KTC8050 625MW
A
Q
100 0501-002375 TRANSISTOR KTC8050 625MW
A
Q
301 0501-000010 TRANSISTOR KTC1008 800MW
A
Q
50L 0501-002375 TRANSISTOR KTC8050 625MW
A
Q
50R 0501-002375 TRANSISTOR KTC8050 625MW
A
Q
603 0501-002375 TRANSISTOR KTC8050 625MW
ARL1 3501-001197 RELAY 12VDC 0.54W
AR10L 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
AR10R 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
AR101 2003-000008 OMF RESISTOR 100 5% 1W
AR102 2001-000660 CARBON RESISTOR 33K 5% 1/8W
AR103 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR104 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR11L 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR11R 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR12L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR12R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR13L 2001-000472 CARBON RESISTOR 2.7K 5% 1/8W
AR13R 2001-000472 CARBON RESISTOR 2.7K 5% 1/8W
AR14L 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR14R 2001-001055 CARBON RESISTOR 1.8K 5% 1/2W
AR15L 2003-000390 OMF RESISTOR 0.27 5% 2W
AR15R 2003-000390 OMF RESISTOR 0.27 5% 2W
AR16L 2001-000017 CARBON RESISTOR 4.7 5% 1/4W
AR16R 2001-000017 CARBON RESISTOR 4.7 5% 1/4W
AR17L 2003-000689 OMF RESISTOR 4.7 5% 1W
AR17R 2003-000689 OMF RESISTOR 4.7 5% 1W
AR18L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR18R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR20L 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR20R 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR200 2003-000008 OMF RESISTOR 100 5% 1W
AR201 2003-000008 OMF RESISTOR 100 5% 1W
AR202 2003-000428 OMF RESISTOR 1.5K 5% 1W
AR203 2003-000428 OMF RESISTOR 1.5K 5% 1W
AR204 2001-000331 CARBON RESISTOR 12K 5% 1/8W
AR21L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR21R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR22L 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR22R 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR23L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR23R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR24L 2009-001117 OMF RESISTOR 0.1 5% 5W
AR24R 2009-001117 OMF RESISTOR 0.1 5% 5W
AR25L 2009-001117 OMF RESISTOR 0.1 5% 5W
AR25R 2009-001117 OMF RESISTOR 0.1 5% 5W
AR26L 2001-000017 CARBON RESISTOR 4.7 5% 1/4W
AR26R 2001-000017 CARBON RESISTOR 4.7 5% 1/4W
AR27L 2003-000689 OMF RESISTOR 4.7 5% 1W
AR27R 2003-000689 OMF RESISTOR 4.7 5% 1W
AR301 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
AR302 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR303 2001-000515 CARBON RESISTOR 220 5% 1/8W
AR50L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR50R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR500 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR501 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR51L 2001-001000 CARBON RESISTOR 82K 5% 1/8W
AR51R 2001-001000 CARBON RESISTOR 82K 5% 1/8W
AR52L 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR52R 2001-000429 CARBON RESISTOR 1K 5% 1/8W
AR53L 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR53R 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR54L 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR54R 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR55L 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
AR55R 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
AR603 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
AZD20 0403-000382 ZENER DIODE UZP15B 15V
AZD21 0403-000382 ZENER DIODE UZP15B 15V
Item
Parts number Parts name Ar
ea
Remarks
A
