JVC MX-GA77 - Page 84

MX-GA77
3-18
Item
Parts number Parts name Ar
ea
Electrical parts list (Amp. board)
Remarks
Block No. 03
A
FIC01 1201-001955 IC STK403-070 14P
FIC02 1201-000191 IC BA4558 8P
HRFS2 3602-000147 FUSE-CLIP
HRFS5 3602-000147 FUSE-CLIP
HRFS6 3602-000147 FUSE-CLIP
HRFS7 3602-000147 FUSE-CLIP
HRFS8 3602-000147 FUSE-CLIP
PCB AH41-00554A PCB-AMP 247 163 1.6T
PCW1 3711-000588 CONNECTOR 10P 1R 2.5MM ST
PW101 3711-000190 CONNECTOR 2P 1R 7.92MM ST
RFS2 3601-001248 FUSE
A
125V 5A
RFS5 3601-001285 FUSE
A
125V 6.3A
RFS6 3601-001285 FUSE
A
125V 6.3A
RFS7 3601-001201 FUSE
A
125V 8A
RFS8 3601-001201 FUSE
A
125V 8A
SPK 3716-001164 TERMINAL-BLOCK SOLDER 8P 60V7A
WIC01 1201-001844 IC STK412-020 18P
