MX-GA77
3-19
Item
Parts number Parts name Ar
ea
Electrical parts list (CD board)
Remarks
Block No. 04
A
CW101 3708-001252 CONNECTOR 16P 1MM ST
CW102 AH39-20561P LEAD CONNECTOR 5295 6P 150MM
CW103 3708-001131 CONNECTOR 5P 1.25MM ST
CW104 3711-003379 CONNECTOR 3P 1R 2.5MM ST
CW105 3708-001438 CONNECTOR 22P 1.25MM AN
CW106 AH39-00060A LEAD CONNECTOR 51015-08 004-08
CW107 3711-000906 CONNECTOR 3P 1R 2MM AN SN
C101 2401-000240 E.CAPACITOR 100UF 20% 10V
C102 2203-001537 CHIP CAPACITOR 1NF 10% 50V
C103 2203-001551 CHIP CAPACITOR 1.5NF 10% 50V
C104 2203-001551 CHIP CAPACITOR 1.5NF 10% 50V
C105 2203-000609 CHIP CAPACITOR 22NF 10% 50V
C106 2203-001137 CHIP CAPACITOR 68NF +80-20% 50V
C107 2401-000240 E.CAPACITOR 100UF 20% 10V
C108 2401-000240 E.CAPACITOR 100UF 20% 10V
C111 2203-000892 CHIP CAPACITOR 4.7NF 10% 50V
C112 2203-000892 CHIP CAPACITOR 4.7NF 10% 50V
C113 2202-000780 C.CAPACITOR 100NF +80-20% 50V
C114 2401-001625 E.CAPACITOR 6.8UF 20% 50V
C115 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C116 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C117 2203-001537 CHIP CAPACITOR 1NF 10% 50V
C118 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C119 2203-000802 CHIP CAPACITOR 33NF 10% 50V
C120 2401-001968 E.CAPACITOR 470NF 20% 50V
C121 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C122 2203-001137 CHIP CAPACITOR 68NF +80-20% 50V
C123 2401-000438 E.CAPACITOR 10UF 20% 25V
C124 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C124A 2203-001064 CHIP CAPACITOR 56NF 10% 50V
C125 2203-000840 CHIP CAPACITOR 0.39NF 5% 50V
C126 2203-000495 CHIP CAPACITOR 2.2NF 10% 50V
C127 2203-000595 CHIP CAPACITOR 0.22NF 5% 50V
C128 2203-000802 CHIP CAPACITOR 33NF 10% 50V
C129 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C130 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C131 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C132 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C133 2401-000240 E.CAPACITOR 100UF 20% 10V
C134 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C135 2401-001968 E.CAPACITOR 470NF 20% 50V
C201 2203-001619 CHIP CAPACITOR 0.027NF 5% 50V
C202 2203-001619 CHIP CAPACITOR 0.027NF 5% 50V
C203 2203-001223 CHIP CAPACITOR 0.82NF 10% 50V
C204 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C205 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C207 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C208 2203-000858 CHIP CAPACITOR 0.039NF 5% 50V
C209 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C211 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C212 2401-000240 E.CAPACITOR 100UF 20% 10V
C213 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C214 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C215 2401-000240 E.CAPACITOR 100UF 20% 10V
C216 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C217 2401-000240 E.CAPACITOR 100UF 20% 10V
C218 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C301 2401-001102 E.CAPACITOR 330UF 20% 16V
C302 2401-000240 E.CAPACITOR 100UF 20% 10V
C303 2401-000240 E.CAPACITOR 100UF 20% 10V
C304 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C305 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C401 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C402 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C403 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C501L 2401-001954 E.CAPACITOR 4.7MF 20% 50V
C501R 2401-001954 E.CAPACITOR 4.7MF 20% 50V
C502L 2203-001537 CHIP CAPACITOR 1NF 10% 50V
C502R 2203-001537 CHIP CAPACITOR 1NF 10% 50V
C601 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C602 2203-000260 CHIP CAPACITOR 10NF 10% 50V
C603 2401-000240 E.CAPACITOR 100UF 20% 10V
C603A 2202-000780 C.CAPACITOR 100NF +80-20% 50V
C604 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C605 2203-001223 CHIP CAPACITOR 0.82NF 10% 50V
C606 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C607 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C608 2203-001223 CHIP CAPACITOR 0.82NF 10% 50V
C610 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C611 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C612 2203-000203 CHIP CAPACITOR 100NF 10% 16V
C801 2401-002183 E.CAPACITOR 220MF 20% 16V
C803 2203-000787 CHIP CAPACITOR 0.33NF 5% 50V
C804 2202-000243 C.CAPACITOR 33PF 5% 50V SL
C805 2202-000243 C.CAPACITOR 33PF 5% 50V SL
C806 2202-000243 C.CAPACITOR 33PF 5% 50V SL
DR1 2007-000872 CHIP RESISTOR 4.7K 5% 1/10W
DR2 2007-000872 CHIP RESISTOR 4.7K 5% 1/10W
D301 0402-000151 DIODE 1N5392 100V 1.5A
IC101 1204-001799 IC KB9226 48P
IC201 0904-001524 IC 5L9290
Q
FP 48P
IC301 1003-000179 IC KA9258D 28P
IC401 1003-001162 IC KA3082 10PIN
IC402 1003-001162 IC KA3082 10PIN
IC601 1204-001885 IC S5L9276 64P
IC602 1105-001339 IC M11L1644 24P
IC801 AC14-12001G IC KA78L05
PCB AH41-00282B PCB-CD G3HI-3CD
Q
101 0501-000314 TRANSISTOR KSA812 150MW
Q
301 0501-000610 TRANSISTOR KSA928A-Y
Q
302 0501-000010 TRANSISTOR KSC1008 800MW
R101 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R102 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R103 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R104 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R105 2007-000409 CHIP RESISTOR 15K 5% 1/10W
R105 2007-001208 CHIP RESISTOR 82K 5% 1/10W
R106 2007-001208 CHIP RESISTOR 82K 5% 1/10W
R107 2007-001216 CHIP RESISTOR 82 5% 1/10W
R108 2007-000308 CHIP RESISTOR 10 5% 1/10W
R110 2007-000409 CHIP RESISTOR 15K 5% 1/10W
R112 2007-001195 CHIP RESISTOR 820K 5% 1/10W
R113 2007-000444 CHIP RESISTOR 180K 5% 1/10W
R114 2007-000001 CHIP RESISTOR 68K 5% 1/10W
R115 2007-001177 CHIP RESISTOR 8.2K 5% 1/10W
R116 2007-000546 CHIP RESISTOR 20K 5% 1/10W
R117 2001-000331 CARBON RESISTOR 12K 5% 1/8W
R118 2007-000477 CHIP RESISTOR 1M 5% 1/10W
R119 2007-001208 CHIP RESISTOR 82K 5% 1/10W
R120 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R121 2007-000409 CHIP RESISTOR 15K 5% 1/10W
R123 2007-000941 CHIP RESISTOR 47K 5% 1/10W
R124 2007-000338 CHIP RESISTOR 120K 5% 1/10W
R125 2007-000338 CHIP RESISTOR 120K 5% 1/10W
R126 2007-001039 CHIP RESISTOR 56K 5% 1/10W
R127 2007-001208 CHIP RESISTOR 82K 5% 1/10W
Item
Parts number Parts name Ar
ea
Remarks
A
