MX-GA77
3-20
Item
Parts number Parts name Ar
ea
Electrical parts list (CD board)
Remarks
Block No. 04
A
R128 2007-000653 CHIP RESISTOR 27K 5% 1/10W
R129 2007-000941 CHIP RESISTOR 47K 5% 1/10W
R132 2007-000300 CHIP RESISTOR 10K 5% 1/10W
R133 2007-000300 CHIP RESISTOR 10K 5% 1/10W
R201 2007-000290 CHIP RESISTOR 100 5% 1/10W
R202 2007-000477 CHIP RESISTOR 1M 5% 1/10W
R203 2007-000290 CHIP RESISTOR 100 5% 1/10W
R204 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R205 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R206 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R207 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R208 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R209 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R210 2007-000572 CHIP RESISTOR 220 5% 1/10W
R211 2001-000429 CARBON RESISTOR 1K 5% 1/8W
R212 2001-000429 CARBON RESISTOR 1K 5% 1/8W
R213 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R301 2008-000140 FUSIBLE RESISTOR 2.2 5% 1/2W
R302 2001-001006 CARBON RESISTOR 82 5% 1/8W
R501L 2007-000282 CHIP RESISTOR 100K 5% 1/10W
R501R 2007-000282 CHIP RESISTOR 100K 5% 1/10W
R502L 2007-000290 CHIP RESISTOR 100 5% 1/10W
R502R 2007-000290 CHIP RESISTOR 100 5% 1/10W
R601 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R602 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R603 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R604 2001-000515 CARBON RESISTOR 220 5% 1/8W
R605 2001-000429 CARBON RESISTOR 1K 5% 1/8W
R801 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R802 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R803 2001-000429 CARBON RESISTOR 1K 5% 1/8W
R804 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R805 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R806 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R807 2007-000872 CHIP RESISTOR 4.7K 5% 1/10W
R808 2007-000872 CHIP RESISTOR 4.7K 5% 1/10W
R809 2007-000872 CHIP RESISTOR 4.7K 5% 1/10W
R809 2007-000300 CHIP RESISTOR 10K 5% 1/10W
R810 2001-000362 CARBON RESISTOR 150 5% 1/8W
R811 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R812 2007-000468 CHIP RESISTOR 1K 5% 1/10W
R813 2007-000941 CHIP RESISTOR 47K 5% 1/10W
X201 2802-000211 RESONATOR 16.93MHZ 0.5%
ZD301 0403-000344 ZENER DIODE UZ3.9B 3.9V
ZD401 0403-000361 ZENER DIODE UZ6.2BSB 6.2V
ZD402 0403-000352 ZENER DIODE UZ4.7BM 4.7V
