JVC MX-GA77 User Manual

MX-GA77
3-11
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
ea
Remarks
A
AC101 2301-000216 M.CAPACITOR 220NF 5% 50V
AC102 2301-000474 M.CAPACITOR 8.2NF 10% 50V
AC103 2301-000390 M.CAPACITOR 15NF 10% 50V
AC104 2301-000216 M.CAPACITOR 220NF 5% 50V
AC105 2301-000419 M.CAPACITOR 27NF 10% 50V
AC106 2301-000449 M.CAPACITOR 47NF 10% 50V
AC107 2301-000375 M.CAPACITOR 100NF 10% 50V
AC108 2301-000375 M.CAPACITOR 100NF 10% 50V
AC109 2301-000419 M.CAPACITOR 27NF 10% 50V
AC110 2301-000216 M.CAPACITOR 220NF 5% 50V
AC111 2201-000144 C.CAPACITOR 0.1NF 5% 50V
AD101 0401-000101 DIODE 1N4148 100V
AD102 0401-000101 DIODE 1N4148 100V
AD103 0401-000101 DIODE 1N4148 100V
AD104 0401-000101 DIODE 1N4148 100V
AE101 2401-001893 E.CAPACITOR 100UF 20% 16V
AE102 2401-001893 E.CAPACITOR 100UF 20% 16V
AE103 2401-001954 E.CAPACITOR 4.7UF 20% 50V
AE104 2401-001954 E.CAPACITOR 4.7UF 20% 50V
AE105 2401-001893 E.CAPACITOR 100UF 20% 16V
AE106 2401-001893 E.CAPACITOR 100UF 20% 16V
AE107 2401-001893 E.CAPACITOR 100UF 20% 16V
AE108 2401-001893 E.CAPACITOR 100UF 20% 16V
AE109 2401-001511 E.CAPACITOR 47UF 20% 16V
AE110 2401-001511 E.CAPACITOR 47UF 20% 16V
AE111 2401-001912 E.CAPACITOR 1UF 20% 50V
AE112 2401-001893 E.CAPACITOR 100UF 20% 16V
AE113 2401-001893 E.CAPACITOR 100UF 20% 16V
AE114 2401-001511 E.CAPACITOR 47UF 20% 16V
AE115 2401-001511 E.CAPACITOR 47UF 20% 16V
AE116 2401-002180 E.CAPACITOR 2.2UF 20% 50V
AE117 2401-003621 E.CAPACITOR 47UF 20% 63V
AIC01 1201-000191 IC BA4558 8P DIP
AIC02 1201-000191 IC BA4558 8P DIP
AIC03 1201-000191 IC BA4558 8P DIP
AIC04 1201-000191 IC BA4558 8P DIP
A
Q
101 0501-002409 TRANSISTOR KTC945Y 600MW
A
Q
102 0501-002409 TRANSISTOR KTC945Y 600MW
A
Q
103 0501-002409 TRANSISTOR KTC945Y 600MW
AR01L 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR01R 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR02L 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR02R 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR03L 2001-000508 CARBON RESISTOR 220K 5% 1/8W
AR03R 2001-000508 CARBON RESISTOR 220K 5% 1/8W
AR101 2001-000563 CARBON RESISTOR 27K 5% 1/8W
AR102 2001-000563 CARBON RESISTOR 27K 5% 1/8W
AR103 2001-000548 CARBON RESISTOR 270K 5% 1/8W
AR104 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR105 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR106 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR107 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR108 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR109 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR110 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR111 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR112 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR113 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR114 2001-000864 CARBON RESISTOR 56K 5% 1/8W
AR115 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR116 2001-000977 CARBON RESISTOR 8.2K 5% 1/8W
AR117 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR118 2001-000508 CARBON RESISTOR 220K 5% 1/8W
AR119 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR120 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR121 2001-000802 CARBON RESISTOR 5.6K 5% 1/8W
AR122 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR123 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
AR124 2001-000331 CARBON RESISTOR 12K 5% 1/8W
AR125 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR126 2001-000522 CARBON RESISTOR 22K 5% 1/8W
AR127 2001-000977 CARBON RESISTOR 8.2K 5% 1/8W
AR128 2001-000660 CARBON RESISTOR 33K 5% 1/8W
AR129 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR130 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR131 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR132 2001-000508 CARBON RESISTOR 220K 5% 1/8W
AR133 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
AR134 2001-001000 CARBON RESISTOR 82K 5% 1/8W
AR135 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR136 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR137 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR138 2001-000786 CARBON RESISTOR 47K 5% 1/8W
AR139 2001-000554 CARBON RESISTOR 270 5% 1/8W
AR140 2001-000802 CARBON RESISTOR 5.6K 5% 1/8W
AR141 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR301 2001-000281 CARBON RESISTOR 100 5% 1/8W
AR302 2001-000290 CARBON RESISTOR 10K 5% 1/8W
BC01L 2301-000361 M.CAPACITOR 1.2NF 10% 50V
BC01R 2301-000361 M.CAPACITOR 1.2NF 10% 50V
BD101 0401-000101 DIODE 1N4148 100V
BL01L AH26-10002W TRANS TRAP-COIL BIAS-TRAP105K
BL01R AH26-10002W TRANS TRAP-COIL BIAS-TRAP105K
B
Q
02L 0501-000010 TRANSISTOR KTC1008 800MW
B
Q
02R 0501-000010 TRANSISTOR KTC1008 800MW
B
Q
03L 0501-000010 TRANSISTOR KTC1008 800MW
B
Q
03R 0501-000010 TRANSISTOR KTC1008 800MW
B
Q
101 0504-001128 DIGI TRANSISTOR KRA103M 400MW
BR01L 2001-000281 CARBON RESISTOR 100 5% 1/8W
BR01R 2001-000281 CARBON RESISTOR 100 5% 1/8W
BR02L 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
BR02R 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
BR03L 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
BR03R 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
BR101 2001-000522 CARBON RESISTOR 22K 5% 1/8W
CE101 2401-000240 E.CAPACITOR 100UF 20% 10V
CE102 2401-001893 E.CAPACITOR 100UF 20% 16V
CE103 2401-001887 E.CAPACITOR 100NF 20% 50V
C
Q
01L 0504-001125 DIGI TRANSISTOR KRC110M 400MW
C
Q
01R 0504-001125 DIGI TRANSISTOR KRC110M 400MW
C
Q
101 0504-001128 DIGI TRANSISTOR KRA103M 400MW
CR01L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
CR01R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
CR02L 2001-000411 CARBON RESISTOR 18K 5% 1/8W
CR02R 2001-000411 CARBON RESISTOR 18K 5% 1/8W
CW101 3708-001577 CONNECTOR 30P 1.25MM
CW103 3708-000412 CONNECTOR 12P 1.25MM
CW104 3711-001137 CONNECTOR 8P 1R 2MM
CW105 3708-001167 CONNECTOR 14P 1.25MM
CW106 AH39-00295A W/HARNESS UNIT MAX-L85 9P
CW107 AH39-00338A LEAD CONNECTOR
CW108 3711-001062 CONNECTOR 6P 1R 2MM
CW109 3711-003111 CONNECTOR 6P 1R 2.5MM
CW110 3711-003107 CONNECTOR 3P 1R 2.5MM
CW111 3711-000907 CONNECTOR 3P 1R 2MM
EC07L 2301-000454 M.CAPACITOR 5.6NF 10% 50V
