MX-GA77
3-12
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
EC07R 2301-000454 M.CAPACITOR 5.6NF 10% 50V
EC08L 2301-000216 M.CAPACITOR 220NF 5% 50V
EC08R 2301-000216 M.CAPACITOR 220NF 5% 50V
EC09L 2301-000216 M.CAPACITOR 220NF 5% 50V
EC09R 2301-000216 M.CAPACITOR 220NF 5% 50V
EC10L 2201-000368 C.CAPACITOR 0.22NF 10% 50V
EC10R 2201-000368 C.CAPACITOR 0.22NF 10% 50V
EC101 2301-000361 M.CAPACITOR 1.2NF 10% 50V
EC102 2301-000375 M.CAPACITOR 100NF 10% 50V
EC103 2201-000783 C.CAPACITOR 100NF +80-20% 50V
EC11L 2201-000368 C.CAPACITOR 0.22NF 10% 50V
EC11R 2201-000368 C.CAPACITOR 0.22NF 10% 50V
ED102 0401-000101 DIODE 1N4148 100V
EE01L 2401-001912 E.CAPACITOR 1UF 20% 50V
EE01R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE02L 2401-001912 E.CAPACITOR 1UF 20% 50V
EE02R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE03L 2401-001917 E.CAPACITOR 1UF 20% 50V
EE03R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE04L 2401-001912 E.CAPACITOR 1UF 20% 50V
EE04R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE05L 2401-001912 E.CAPACITOR 1UF 20% 50V
EE05R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE06L 2401-001919 E.CAPACITOR 2.2UF 20% 50V
EE06R 2401-001919 E.CAPACITOR 2.2UF 20% 50V
EE07L 2401-001917 E.CAPACITOR 1UF 20% 50V
EE07R 2401-001912 E.CAPACITOR 1UF 20% 50V
EE08L 2401-001917 E.CAPACITOR 1UF 20% 50V
EE08R 2401-001917 E.CAPACITOR 1UF 20% 50V
EE101 2401-000438 E.CAPACITOR 10UF 20% 25V
EE102 2401-001511 E.CAPACITOR 47UF 20% 16V
EE103 2401-000778 E CAPACITOR 220UF 20% 10V
EE107 2401-001954 E.CAPACITOR 4.7UF 20% 50V
EE108 2401-001954 E.CAPACITOR 4.7UF 20% 50V
EE109 2401-000759 E.CAPACITOR 220NF 20% 50V
EIC01 1204-001776 IC TDA7442D 28P
EIC02 1201-000191 IC BA4558 8P DIP
EJ101 3722-000379 JACK-PIN 4P/2C 3.5MM
E
Q
101 0501-002409 TRANSISTOR KTC945Y 600MW
ER01L 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER01R 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER02L 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
ER02R 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
ER03L 2001-000411 CARBON RESISTOR 18K 5% 1/8W
ER03R 2001-000411 CARBON RESISTOR 18K 5% 1/8W
ER04L 2001-000411 CARBON RESISTOR 18K 5% 1/8W
ER04R 2001-000411 CARBON RESISTOR 18K 5% 1/8W
ER05L 2001-000515 CARBON RESISTOR 220 5% 1/8W
ER05R 2001-000515 CARBON RESISTOR 220 5% 1/8W
ER06L 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER06R 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER07L 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
ER07R 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
ER08L 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER08R 2001-000786 CARBON RESISTOR 47K 5% 1/8W
ER09L 2001-000290 CARBON RESISTOR 10K 5% 1/8W
ER09R 2001-000290 CARBON RESISTOR 10K 5% 1/8W
ER10L 2001-000273 CARBON RESISTOR 100K 5% 1/8W
ER10R 2001-000273 CARBON RESISTOR 100K 5% 1/8W
ER101 2001-000515 CARBON RESISTOR 220 5% 1/8W
ER102 2001-000515 CARBON RESISTOR 220 5% 1/8W
ER103 2001-000023 CARBON RESISTOR 47 5% 1/4W
ER104 2001-000023 CARBON RESISTOR 47 5% 1/4W
ER109 2001-000290 CARBON RESISTOR 10K 5% 1/8W
ER110 2001-000773 CARBON RESISTOR 470K 5% 1/8W
ER111 2001-000515 CARBON RESISTOR 220 5% 1/8W
ER112 2001-000645 CARBON RESISTOR 330K 5% 1/8W
ER113 2001-000989 CARBON RESISTOR 820K 5% 1/8W
ER13L 2001-000864 CARBON RESISTOR 56K 5% 1/8W
ER13R 2001-000864 CARBON RESISTOR 56K 5% 1/8W
ER14L 2001-000008 CARBON RESISTOR 15K 5% 1/8W
ER14R 2001-000008 CARBON RESISTOR 15K 5% 1/8W
ER15L 2001-000290 CARBON RESISTOR 10K 5% 1/8W
ER15R 2001-000290 CARBON RESISTOR 10K 5% 1/8W
ER16L 2001-000003 CARBON RESISTOR 330 5% 1/8W
ER16R 2001-000003 CARBON RESISTOR 330 5% 1/8W
ER17L 2001-000003 CARBON RESISTOR 330 5% 1/8W
ER17R 2001-000003 CARBON RESISTOR 330 5% 1/8W
EZD01 0403-000372 ZENER DIODE UZ9.1BM 9.1V
EZD02 0403-000372 ZENER DIODE UZ9.1BM 9.1V
HC01L 2201-000642 C.CAPACITOR 0.68NF 10% 50V
HC01R 2201-000642 C.CAPACITOR 0.68NF 10% 50V
HE01L 2401-001912 E.CAPACITOR 1UF 20% 50V
HE01R 2401-001912 E.CAPACITOR 1UF 20% 50V
HE02L 2401-001164 E.CAPACITOR 33UF 20% 16V
HE02R 2401-001164 E.CAPACITOR 33UF 20% 16V
HE101 2401-000830 E.CAPACITOR 220UF 20% 25V
HE102 2401-000830 E.CAPACITOR 220UF 20% 25V
HE103 2401-001511 E.CAPACITOR 47UF 20% 16V
HIC01 1201-000461 IC BA4558 8P SOIC
H
Q
01L 0501-002375 TRANSISTOR KTC8050 625MW
H
Q
01R 0501-002375 TRANSISTOR KTC8050 625MW
HR01L 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
HR01R 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
HR02L 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
HR02R 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
HR03L 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
HR03R 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
HR04L 2001-000290 CARBON RESISTOR 10K 5% 1/8W
HR04R 2001-000290 CARBON RESISTOR 10K 5% 1/8W
HR05L 2001-000019 CARBON RESISTOR 10 5% 1/2W
HR05R 2001-000019 CARBON RESISTOR 10 5% 1/2W
HR06L 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
HR06R 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
HR101 2001-000028 CARBON RESISTOR 100 5% 1/2W
HR102 2001-000019 CARBON RESISTOR 10 5% 1/2W
HR103 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
HR104 2001-000290 CARBON RESISTOR 10K 5% 1/8W
JC00L 2201-000368 C.CAPACITOR 0.22NF 10% 50V
JC00R 2201-000368 C.CAPACITOR 0.22NF 10% 50V
JC01L 2201-000642 C.CAPACITOR 0.68NF 10% 50V
JC01R 2201-000642 C.CAPACITOR 0.68NF 10% 50V
JC02L 2301-000379 M.CAPACITOR 10NF 10% 50V
JC02R 2301-000379 M.CAPACITOR 10NF 10% 50V
JC03L 2301-000375 M.CAPACITOR 100NF 10% 50V
JC03R 2301-000375 M.CAPACITOR 100NF 10% 50V
JC04L 2301-000375 M.CAPACITOR 100NF 10% 50V
JC04R 2301-000375 M.CAPACITOR 100NF 10% 50V
JC05L 2301-000430 M.CAPACITOR 33NF 10% 50V
JC05R 2301-000430 M.CAPACITOR 33NF 10% 50V
JC06L 2201-000674 C.CAPACITOR 0.82NF 10% 50V
JC06R 2201-000674 C.CAPACITOR 0.82NF 10% 50V
JC101 2201-000557 C.CAPACITOR 0.47NF 10% 50V
JC102 2301-000407 M.CAPACITOR 2.7NF 10% 50V
JC103 2301-000404 M.CAPACITOR 2.2NF 10% 50V
JC104 2301-000404 M.CAPACITOR 2.2NF 10% 50V
Item
Parts number Parts name Ar
ea
Remarks
A
