MX-GA77
3-13
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
JC105 2202-000781 C.CAPACITOR 100PF 10% 50V
JC106 2202-000781 C.CAPACITOR 100PF 10% 50V
JC107 2202-000781 C.CAPACITOR 100PF 10% 50V
JC108 2202-000781 C.CAPACITOR 100PF 10% 50V
JD101 0401-000101 DIODE 1N4148 100V
JE01L 2401-002180 E.CAPACITOR 2.2UF 20% 50V
JE01R 2401-002180 E.CAPACITOR 2.2UF 20% 50V
JE02L 2401-002180 E.CAPACITOR 2.2UF 20% 50V
JE02R 2401-002180 E.CAPACITOR 2.2UF 20% 50V
JE101 2401-001511 E.CAPACITOR 47UF 20% 16V
JE102 2401-001164 E.CAPACITOR 33UF 20% 16V
JE103 2401-001912 E.CAPACITOR 1UF 20% 50V
JE104 2401-001164 E.CAPACITOR 33UF 20% 16V
JE105 2401-000438 E.CAPACITOR 10UF 20% 25V
JIC01 1201-001899 IC HA12237F 40P
JL101 2701-000298 INDUCTOR 470UH 10%
JL102 AH26-10003C TRANS TRAP-COIL PCHNS-5371E
Q
J
J
Q
01L 0501-002375 TRANSISTOR KTC8050 625MW
J
Q
01R 0501-002375 TRANSISTOR
Item
Parts num
ber
Parts nam
e
Area
Rem
arks
A
KTC8050 625MW
J
Q
101 0501-002176 TRANSISTOR KTD863 1W
J
Q
102 0501-000422 TRANSISTOR KTA1273
J
Q
103 0501-002409 TRANSISTOR KTC945B
J
Q
104 0504-001128 DIGI TRANSISTOR KRA103M 400MW
JR01L 2001-000977 CARBON RESISTOR 8.2K 5% 1/8W
JR01R 2001-000977 CARBON RESISTOR 8.2K 5% 1/8W
JR02L 2001-000241 CARBON RESISTOR 1.5K 5% 1/8W
JR02R 2001-000241 CARBON RESISTOR 1.5K 5% 1/8W
JR03L 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
JR03R 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
JR04L 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
JR04R 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
JR05L 2001-000802 CARBON RESISTOR 5.6K 5% 1/8W
JR05R 2001-000802 CARBON RESISTOR 5.6K 5% 1/8W
JR06L 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
JR06R 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
JR07L 2001-000302 CARBON RESISTOR 10 5% 1/8W
JR07R 2001-000302 CARBON RESISTOR 10 5% 1/8W
JR08L 2001-000008 CARBON RESISTOR 15K 5% 1/8W
JR08R 2001-000008 CARBON RESISTOR 15K 5% 1/8W
JR101 2001-000290 CARBON RESISTOR 10K 5% 1/8W
JR102 2001-000456 CARBON RESISTOR 2.2 5% 1/4W
JR103 2001-000023 CARBON RESISTOR 47 5% 1/4W
JR104 2001-000786 CARBON RESISTOR 47K 5% 1/8W
JR105 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
JR106 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
JR107 2001-000429 CARBON RESISTOR 1K 5% 1/8W
JR108 2001-000290 CARBON RESISTOR 10K 5% 1/8W
JR109 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
JR110 2001-000281 CARBON RESISTOR 100 5% 1/8W
JR112 2001-000435 CARBON RESISTOR 1M 5% 1/8W
JR113 2001-000522 CARBON RESISTOR 22K 5% 1/8W
JVR01 2103-000248 ROTA V RESISTOR 200K 30% 1/10W
JVR02 2103-000248 ROTA V RESISTOR 200K 30% 1/10W
PBD01 0402-000450 DIODE-BRIDGE
A
GBU606 600V 6A
PBD02 0402-001258 DIODE-BRIDGE
A
GBU606 600V 6A
PBD03 0402-001077 DIODE-BRIDGE
A
KBP202G 200V 2A
PCB AH41-00555A PCB MAIN MX-GA77
PC201 2201-000161 C.CAPACITOR
A
10NF +80-20% 500V
PC202 2201-000161 C.CAPACITOR
A
10NF +80-20% 500V
PC203 2201-000161 C.CAPACITOR
A
10NF +80-20% 500V
PD201 0402-000127 DIODE 1N4002 100V 1A
PD202 0402-000127 DIODE 1N4002 100V 1A
PD203 0402-000127 DIODE 1N4002 100V 1A
PD204 0402-000127 DIODE 1N4002 100V 1A
PD205 0401-000101 DIODE 1N4148 100V
PD206 0401-000101 DIODE 1N4148 100V
PD209 0402-000127 DIODE 1N4002 100V 1A
PD210 0402-000127 DIODE 1N4002 100V 1A
PE201 2401-001067 E.CAPACITOR
A
3300UF 20% 42V
PE202 2401-001067 E.CAPACITOR
A
3300UF 20% 42V
PE203 2401-003381 E.CAPACITOR
A
3300UF 20% 63V
PE204 2401-003381 E.CAPACITOR
A
3300UF 20% 63V
PE205 2401-003116 E.CAPACITOR
A
4700UF 20% 35V
PE206 2401-000830 E.CAPACITOR 220UF 20% 25V
PE207 2401-001938 E.CAPACITOR 22UF 20% 25V
PE208 2401-000407 E.CAPACITOR 10UF 20% 16V
PE209 2401-001912 E.CAPACITOR 1UF 20% 50V
PE210 2401-001912 E.CAPACITOR 1UF 20% 50V
PE211 2401-001954 E.CAPACITOR 4.7UF 20% 50V
PE212 2401-000230 E.CAPACITOR 100UF 20% 100V
PE213 2401-000385 E.CAPACITOR 10UF 20% 100V
PE214 2401-000438 E.CAPACITOR 10UF 20% 25V
PF101 2008-000135 FUSIBLE RESISTOR
A
1 5% 1/2W
PIC02 1203-001653 REGULATOR L4959
PL102 2701-000298 INDUCTOR 470UH 10%
P
Q
102 0504-000144 DIGI TRANSISTOR KSR2002 300MW
P
Q
103 0504-001123 DIGI TRANSISTOR KRC103M 400MW
P
Q
104 0501-000331 TRANSISTOR KSC1009-Y
P
Q
105 0501-000422 TRANSISTOR KTA1273
P
Q
106 0501-002408 TRANSISTOR MPS751
PR201 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
PR202 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
PR203 2001-000429 CARBON RESISTOR 1K 5% 1/8W
PR204 2001-000786 CARBON RESISTOR 47K 5% 1/8W
PR205 2001-000290 CARBON RESISTOR 10K 5% 1/8W
PR206 2003-000455 OMF RESISTOR 100 5% 2W
PR207 2001-000563 CARBON RESISTOR 27K 5% 1/8W
PR208 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
PR209 2001-000111 CARBON RESISTOR 150 5% 1/4W
PR210 2001-000055 CARBON RESISTOR 4.7K 5% 1/4W
PR211 2001-000038 CARBON RESISTOR 390 5% 1/4W
PR212 2001-000429 CARBON RESISTOR 1K 5% 1/8W
PR213 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
PR214 2001-000613 CARBON RESISTOR 3.9K 5% 1/8W
PR215 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
PR216 2003-000701 OMF RESISTOR 470 5% 2W
PR217 2001-001153 CARBON RESISTOR 47 5% 1/2W
PR218 2001-001153 CARBON RESISTOR 47 5% 1/2W
PR219 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
PR220 2001-000290 CARBON RESISTOR 10K 5% 1/8W
PR221 2001-000660 CARBON RESISTOR 33K 5% 1/8W
PR222 2001-000244 CARBON RESISTOR 1.5M 5% 1/8W
PZ101 0403-000354 ZENER DIODE UZ5.1B 5.1V
PZ102 0403-000564 ZENER DIODE TZP16A 16V
PZ103 0403-000564 ZENER DIODE TZP16A 16V
PZ104 0403-000393 ZENER DIODE UZP5.1B 5.1V
PZ105 0403-000379 ZENER DIODE UZP12B 12V
RFS9 3601-001295 FUSE
A
125V 4A FAST
