JVC MX-GA77 User Manual

MX-GA77
3-14
Item
Parts number Parts name Ar
ea
Electrical parts list (Front board)
Remarks
Block No. 02
A
BUZZ1 3002-001134 BUZZER 85DB 12V
CW01B AH39-00247A LEAD CONNECTOR
FR101 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR102 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR103 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR104 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR105 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR106 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR107 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR108 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR109 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR110 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR111 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR112 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR113 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR114 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR115 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR116 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR117 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR118 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR119 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR120 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR121 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR122 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR123 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR124 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR125 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR126 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR127 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR128 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR129 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR130 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR131 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR132 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR133 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR134 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR135 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR136 2001-000786 CARBON RESISTOR 47K 5% 1/8W
FR140 2001-000995 CARBON RESISTOR 820 5% 1/8W
FR141 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR142 2001-000221 CARBON RESISTOR 1.2K 5% 1/8W
FR143 2001-000241 CARBON RESISTOR 1.5K 5% 1/8W
FR144 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
FR145 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
FR146 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
FR147 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
FR148 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR149 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR150 2001-000522 CARBON RESISTOR 22K 5% 1/8W
FR151 2001-000010 CARBON RESISTOR 68K 5% 1/8W
FR152 2001-000995 CARBON RESISTOR 820 5% 1/8W
FR153 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR154 2001-000221 CARBON RESISTOR 1.2K 5% 1/8W
FR155 2001-000241 CARBON RESISTOR 1.5K 5% 1/8W
FR156 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
FR157 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
FR158 2001-000591 CARBON RESISTOR 3.3K 5% 1/8W
FR159 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR160 2001-000890 CARBON RESISTOR 6.8K 5% 1/8W
FR161 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR162 2001-000522 CARBON RESISTOR 22K 5% 1/8W
FR201 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR202 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR203 2001-000034 CARBON RESISTOR 220 5% 1/4W
FR204 2001-000855 CARBON RESISTOR 560 5% 1/4W
FR205 2001-000995 CARBON RESISTOR 820 5% 1/8W
FR206 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR207 2001-000221 CARBON RESISTOR 1.2K 5% 1/8W
FR208 2001-000241 CARBON RESISTOR 1.5K 5% 1/8W
FR209 2001-000258 CARBON RESISTOR 1.8K 5% 1/8W
FR210 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
FR211 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR212 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR213 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR214 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR215 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR216 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
FR217 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR218 2001-000508 CARBON RESISTOR 220K 5% 1/8W
FR219 2001-000793 CARBON RESISTOR 47 5% 1/8W
FR220 2001-000295 CARBON RESISTOR 10M 5% 1/8W
FR221 2001-000850 CARBON RESISTOR 560K 5% 1/8W
FR222 2001-000435 CARBON RESISTOR 1M 5% 1/8W
FR223 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR224 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR225 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR226 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR227 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR228 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR229 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR230 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR231 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR232 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR233 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR234 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR235 2001-000429 CARBON RESISTOR 1K 5% 1/8W
FR236 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR237 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR238 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR239 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR240 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR241 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR242 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR243 2001-000281 CARBON RESISTOR 100 5% 1/8W
FR244 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR245 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR246 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR247 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR248 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR249 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR250 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR251 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR252 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR253 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR254 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR255 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR256 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR257 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR258 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR259 2001-000290 CARBON RESISTOR 10K 5% 1/8W
FR260 2001-000522 CARBON RESISTOR 22K 5% 1/8W
FR261 2001-000522 CARBON RESISTOR 22K 5% 1/8W
FR262 2001-000522 CARBON RESISTOR 22K 5% 1/8W
FR263 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
FR264 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
FR265 2001-000522 CARBON RESISTOR 22K 5% 1/8W
Item
Parts number Parts name Ar
ea
Remarks
A
