Item
Parts number Parts name Area
A
Parts list (CD changer mechanism)
Q'ty
Description
Block No. MAMM
1 AH66-80022A
SLIDE CAM
1
ABS HF-380 NTR
2 AH66-60034A
BELT LOAD
1
CR
3 AH66-20186A
GEAR PULLEY
1
POM (M90-44)WHT
4 AH66-20187A
GEAR-LOAD
1
POM (M90-44)BLK
5 AH66-20188A
GEAR-CAM
1
POM(M90-44)WHT
6 AH66-20189A
GEAR-TRAY
1
POM(M90-44)BLK
7 AH66-20190A
GEAR-CONVERTOR
1
POM (M90-44) WH
8 AH66-20191A
GEAR-SYNCRO
1
ABS HF-380 NTR
9 AH66-20192A
GEAR-WORM
1
POM (M90-44)WHT
10 AH31-12001A
LOADING MOTOR
1
FF-030PN-09120
11 AH66-20193A
GEAR-ROULETTE
1
POM(M90-44)BLK
12 AH66-90056A
TRAY-ROULETTE
1
ABS XR-401 BLK
13 AH66-90055A
TRAY DISC
1
ABS XR-401 BLK
14 AH32-10001F
SENSOR
1
KPI-L06
15 AH61-20428A-1
BASE MAIN
1
CMS-300,BLK
16 3302-000159
MAGNET-FERRITE
1
3500-3800G,6P
17 AH66-90053A
TABTE-CHUCK UNI
1
BLK,CMS300
18 AH63-00068B
SHEET CHUCK
1
HYMERON,BLK,0.4
19 3404-000101
SWICH MICRO
1
MLS-24
20 AH31-10021A
DC MORTOR
1
RF-500TB,9VDC
21 AH66-10008A
PULLEY-MOTOR
1
BLK,CMS-CR3
22 AH73-10031A
RUBBER-CD
1
RCD380,RED
23 AH91-60150C
SP MOTOR ASS'Y
1
CMS-D73SG6U
24 AH66-30098A
LEVER-LIFTER
1
ABS(BLK),CMS-30
25 AH30-00007A
CD PICKUP
1
SOH-AD3
26 AH73-10034A
RUBBER-CD(G)
1
CMS-300D,GREEN
27 AH61-00255A
BRKT CHUCK
1
SECL 0.8T
