Installation instructions Product description
Kaba c-lever k2evo702en-2012-05 9
3 Product description
3.1 Scope of supply
The Kaba c-lever is supplied with the following accessories:
- 1 Outer furniture with antenna
- 1 Inside shield
- 1 Coupling unit
- 1 Direction pin (large)
- 1 Direction pin (small)
- 1 Spindle
- 1 Connection cord
- 2 batteries, type AA Lithium
- 1 3mm Allen key
- 1 1.5mm Allen key
- Various fixing materials
- 1 quick reference guide
- 1 Drilling template
3.2 Additional accessories
- Adapter pins (product number 1355-42A)
- Programming cable (product number 1355-42)
- Kaba 1460 Programmer
- Kaba media
- Kaba evolo Manager software
- Kaba s-module (Mifare) for external power supply (12-24 V AC/DC, > 300mA)
3.3 Preparatory measures
3.3.1 Door requirements
The door thickness must be between 39 mm and 100 mm. An extension kit is
required if a door is thicker than 63mm.
3.3.2 Lock requirements
The Kaba c-lever can be used with most commercially-available door locks. Only
use locks from established manufacturers, as this is the only way to ensure that
furniture drillings conform to the standards.
Locks with a split follower cannot be used!
To guarantee emergency opening with the help of the locking cylinder, door
locks with a key operated latch must be fitted!
