Kalerm KLM1602 - Description of Internal Components

2.2 Description of internal components
1
2
3
5
6
7
8
9
10
11
12
13
14
16
17
21
18
9
15
4
Thermoblock
Solenoid valve 2W
Geared motor
Dispenser valve 2W
Support
PCBA
Pump
Drainage valve
Line pencil connector
Transformer
Base
Brew unit
Drip tray microswitch
Reed sensor
Flowmeter
Valve support
Control panel
Grinder group
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Structure
