3. Take out back cover according
to the arrow direction
Repair
Service Manual
Intelligent Fresh Ground Coffee Machine
KLM1602
1. Disassemble the 2 screws from
the bottom
2. Take out front cover right and front
cover left separately according to the
direction of the arrow
4.2.1.3 Disassemble front cover right and front cover left
1. Take out right side section
according to the direction of the
arrow
4.2.1.4 Disassemble right cover
