3 Driveline / axle
3.2 Propeller shaft
Examine the universal joints and tighten the
mounting
1 Tighten the propeller shaft mounting screws (A) (16 pcs.).
Tightening torque 160 Nm (118 ft-lb).
Each end of the propeller shaft has four mounting plates with
two mounting screws.
2 Examine the universal joints for:
•
Visible wear in the joints
•
Radial and lateral play (free movement)
3 Driveline / axle – 3.2 Propeller shaft 3
TL2 Maintenance Manual
591 003 Default
