6.3 Tyres and rims
Tighten the wheel mounting nuts
1 The wheel is mounted on the axle with ten nuts. Examine the
condition of the threads of the wheel mounting scews and
nuts when installing the wheel. The threads must be intact
and clean. Lubricate the threads lightly.
2 Fasten the nuts and tighten them to 600 Nm in the order
described in the figure. Examine the tightness of the nuts after
operating the machine for 1 day, at the latest.
Examine the trye pressure
Tyre pressure is checked when the tyre is cold.
For correct tyre pressure, see Section F Technical data .
11
22
33
44
55
66
77
88
99
1010
