3.1 Air drier
4. Air drier water separator container (6 litres)
6. Charging valve that fills the pneumatic system with compressed
air if the engine is not working or the compressor cannot be used
7. Drain valve
8. Four-circuit protection valve
9. Air tanks (2 x 30 litres)
10B. Pressure switch and measurement sensor
The measurement sensor is available as an option.
11. Front pedal valve
11B. The rear pedal valve and shuttle valve in tractors equipped
with a revolving seat
12. Brake light switch
14. Parking brake indicator light switch
15. Shuttle valve
16. Brake pressure quick release valve
17. Rear axle brakes and parking brake spring chamber
18. Front axle brakes
The parking brake spring chamber is an option.
19. Pressure measurement fitting
59. Parking brake solenoid valve
60. Parking brake relay valve
64B. Trailer brake control valve for the EC-compliant brake system
65. Parking brake release
68. Parking brake valve for the EC-compliant brake system
69. Air tank (30 litres) for the EC-compliant brake system
A Foreword – Reading this manual 9
TL2 Maintenance Manual
