12 Common pneumatics
12.2 Tanks and accumulators
Drain the air tanks
The air tanks are located under the chassis.
1 Drain the water from the reservoirs by pulling the cord (A)
attached to the valve ring at the bottom of the reservoir. The
exiting compressed air forces the water out.
12 Common pneumatics – 12.2 Tanks and accumulators 3
TL2 Maintenance Manual
591 003 Default
