DIP SWITCHES SETTINGS
FOR MB14281
DIP SWITCHES SETTINGS
FOR MB3L
FRONT VIEW
*TYPE ONE LETTER PER BOARD IN A CUSTOM
MESSAGE TO HELP WITH SETTINGS DIP SWITCHES
*SKIP THE LETTER "i" AS IT DISPLAYS UNEVENLY
*START FROM LEFT SIDE
AND WORK TOWARDS THE RIGHT
A B C D
E F G H
J K L M
N O P Q
R S T
W X Y
U
V
**CHECK LOCAL CODES FOR ALL MEASUREMENTS**
DATE:
DATE:
DRAWN BY:
CHECKED BY:
PRORIETARY AND CONFIDENTIAL
The information contained in this drawing is the sole property
of K & K Systems. Any reproduction in part or as a whole
without the written permission of K & K Systems is prohibited.
TITLE:
K & K SYSTEMS
DWG. NO.
Oce: (888) 414-3003
www.k-ksystems.com
Scale:
---
Size:
8.5 X 11
Sheet:
1 of 1
Revision:
Timothy P.
FRANK A.
9002 DIP SWITCHES
11-24-20
11-24-20
*DIP SWITCH
NOT TO SCALE
START HERE
END HERE
EXAMPLE
OF LETTER "A"
1 on 2 on 1,2 on 3 on 1,3 on 2,3 on 1,2,3 on 4 on
1,8 on 2,8 on 1,2,8 on 3,8 on 1,3,8 on 2,3,8 on 1,2,3,8 on 4,8 on
1,7 on 2,7 on 1,2,7 on 3,7 on 1,3,7 on 2,3,7 on 1,2,3,7 on 4,7 on
FRONT VIEW
3 L DIP SWITCHES
Size:
Sheet:
DWG. NO.
TITLE:
NAME
DATE
DRAWN
CHECKED
K & K SYSTEMS
Oce: (662) 566-2025
www.k-ksystems.com
PRORIETARY AND CONFIDENTIAL
A B C D
J K L M
R S T U
E F G H
N O P Q
V W X Y
*SKIP THE LETTER “i” AS IT DISPLAYS UNEVENLY.
*TYPE ONE LETTER PER BOARD IN A CUSTOM
MESSAGE TO HELP WITH SETTINGS DIP SWITCHES
FRANK AVILA 09/11/2020FRANK AVILA
9001 DIP SWITCHES
To Next Page
