Kane 358 - INSTRUMENT LAYOUT

7KANE 358 MANUAL
INSTRUMENT LAYOUT
Battery
charger
Watertrap drain with
red plug
Flue probe
temperature T1
Inlet temperature T2
Pressure
connection P1
Pressure
connection P2
(Differential)
Flue gas
inlet
On / Off
Function buttons
- see below
Water trap &
particle filter
Rotary switch
Red connector
– plugs into Flue
Gas Inlet
Flue Probe Temperature Plug –
plugs into T1
The narrower (+ve) pin must be
on the right hand side
Flue Probe Hose
