- 6
Tekniske data
1.783-302.0
1.783-310.0
1.783-311.0
1.783-316.0
1.783-300.0 1.783-303.0
Effekt
Mærkespænding V/Hz 220...240 /
1~50
230 / 1~50 230 / 1~60
Mellemste optagne effekt W 1900
Sugemotorydelse W 500
Børstemotorydelse W 2100
Kapacitet, max. 2710 2210 2710
Maksimalt tilladelig netimpedans Ohm 0.255+j0.159 0,256+j0,160
Forlængerkabel 10 m mm
2
1,5
Forlængerkabel 30 m mm
2
2,5
Sugning
Sugeeffekt, luftmængde l/s 20
Sugeeffekt, undertryk kPa 10
Rengøringsbørster
Arbejdsbredde mm 400
Børstediameter mm 96
Børsteomdrejningstal 1/min 1100 1350
Mål og vægt
Teoretisk fladeydelse m²/h 400
Volumen frisk-/snavsevandsbeholder l 10
Længde (uden bøjle) mm 520
Bredde (uden sugebjælke) mm 470
Højde (uden bøjle) mm 380
Vægt kg 44,5 43 44,5
Oplyste værdier ifølge EN 60335-2-67
Hånd-arm vibrationsværdi m/s
2
<2,5
Usikkerhed K m/s
2
0,2
Lydtryksniveau L
pA
dB(A) 74
Usikkerhed K
pA
dB(A) 1
Lydeffektniveau L
WA
dB(A) 87
Usikkerhed K
WA
dB(A) 1
57DA

Table of Contents

Other manuals for Kärcher BR 40/10 C Adv

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher BR 40/10 C Adv and is the answer not in the manual?

Kärcher BR 40/10 C Adv Specifications

General IconGeneral
AC input voltage230 V
AC input frequency60 Hz
Maximum input power2300 W
Maximum area performance400 m²/h
Fresh water tank capacity10 L
Brush rotation speed (min)1100 RPM
Practical area performance300 m²/h
Brush contact pressure (max)200 g/cm²
Brush contact pressure (min)100 g/cm²
Weight and Dimensions IconWeight and Dimensions
Depth470 mm
Width520 mm
Height380 mm
Weight30000 g
