Coded error messages
The following coded error messages can occur when operating
the level V engines V2403-CR-TE4B-KRC-1 (MC 130 plus, MC
130 classic).
When an error is indicated while the engine is running, the indi-
cator lamp flashes and an error code may also be shown on the
display.
Hydraulic oil temperature too high. Operate the engine in idling mixture until the warning
light goes out.
Hydraulic oil temperature too low. Carefully warm up the engine until the warning light
goes out.
Engine oil pressure is too high. Call Customer Service.
Parking brake active. Release the parking brake.
Low fuel level. Top up the fuel.
Vent the fuel system if the tank was run dry.
Battery is not charging. Call Customer Service.
Regeneration process required. Perform regeneration, see Start regeneration.
Service required. Have the device serviced by Customer Service.
a The service display must be reset by Customer Ser-
vice.
Malfunction Cause Remedy
NCD error Indicator lamp blinks
U0076 1Hz (one second interval) + on for 5 seconds +
1 Hz (one second interval) + on for 5 seconds ...
P0102 1Hz + on for 5 seconds + 1 Hz + on for 5 sec-
onds ...
PCD Error Indicator lamp blinks
P3014 1 Hz (1 second interval)
P1A28 1 Hz (1 second interval)
P3015 1 Hz (1 second interval)
P2455 1 Hz (1 second interval)
NCD error Indicator lamp blinks
Malfunction Cause Remedy
U0076 No communication with the exhaust gas
return
Engine loses power and the exhaust emission perfor-
mance becomes worse
a Contact Customer Service
P0102 Air mass sensor abnormal Engine loses power and the exhaust emission perfor-
mance becomes worse
a Contact Customer Service
P03014 / P1A28 Fault in the DPF system Engine loses power and the exhaust emission perfor-
mance becomes worse
a Contact Customer Service
P3015 No DPF function Engine loses power and the exhaust emission perfor-
mance becomes worse
a Contact Customer Service
P2455 Differential sensor abnormal No change in behaviour
a Contact Customer Service
